Building Essentia with CMake

Building music analysis library Essentia with CMake

Essentia is a library for audio and music analysis, description and synthesis. Though you can find build instructions on https://essentia.upf.edu/installing.html, those won’t help you much compiling Essentia with a recent version of Visual Studio. The original build script is based on Python Waf, which seems a natural choice since the project also provides Python bindings and a large part of the GitHub repository is taken up by Jupyter notebooks. On the other hand, Essentia is a C++ library at its core, so I thought a CMake build script might be useful. The project is available at https://github.com/wo80/essentia/tree/cmake.

Prerequisites

Essentia depends on the following libraries:

  • Eigen: for linear algebra
  • FFTW: for the FFT implementation (optional)
  • FFmpeg: avcodec/avformat/avutil/swresample for loading/saving any type of audio files (optional)
  • libsamplerate: for resampling audio (optional)
  • TagLib: for reading audio metadata tags (optional)
  • YAML: for YAML files input/output (optional)
  • Chromaprint: for audio fingerprinting (optional)
  • Gaia: for using SVM classifier models (optional)
  • TensorFlow: for inference with TensorFlow deep learning models (optional)
  • VAMP SDK: for the VAMP plugin (optional)

Building Essentia on Windows

To ensure a smooth build, follow the instructions on managing C/C++ library dependencies on Windows when installing the dependencies. You can download most of them from my package site.

A batch script build-dependencies-msvc.bat is now available to fetch all dependencies. Take a look at the Github cmake workflow to see how this can be used to build Essentia.

A full FFmpeg Windows build is available at github.com/GyanD/codexffmpeg. If you want to build an audio-only version of FFmpeg, take a look at the Compiling audio-only FFmpeg on Windows post. A Github workflow with audio-only FFmpeg releases providing static and shared libraries for Visual Studio is available at github.com/wo80/ffmpeg-audio-only.

Despite Eigen being a header only library, recent releases come with a CMake build system. Follow the usual CMake practices and install Eigen according to the instructions in the blog post mentioned above.

If you want to use Gaia2 SVM models with Essentia, use the CMake project available at https://github.com/wo80/gaia/tree/cmake. This will also add a dependency on Qt5. You can find build instructions for Qt in Compiling Qt with Visual C++ compiler on Windows.

Note that the Gaia code is no longer maintained and support for the SVM models will probably be removed in a future version of Essentia. It is recommended to use the TensorFlow models instead.

To use TensorFlow models with Essentia, use the following package:

More recent versions may be found on tensorflow.org, but weren’t tested by me.

Building with CMake

First, clone the repository (including submodules for Essentia test data and machine learning models) and switch to the cmake branch:

git clone --recurse-submodules https://github.com/wo80/essentia.git
cd essentia
git switch cmake

The CMake script provides the following configuration options:

  • BUILD_TESTS: Build tests (default ON)
  • BUILD_EXAMPLES: Build examples (default OFF)
  • BUILD_PYTHON_BINDINGS: Build Python bindings (default OFF)
  • BUILD_VAMP_PLUGIN: Build VAMP plugin (default OFF)
  • USE_TENSORFLOW: Use TensorFlow (default OFF)
  • USE_GAIA2: Use Gaia2 (default OFF)

Configure and build the project, then run the tests:

cmake -B build -D BUILD_EXAMPLES=ON
cmake --build build --config Release
ctest --test-dir build --output-on-failure -C Release

Install the project (adjust install prefix) with:

cmake --install build --config Release --prefix /path/to/install

Building a Python wheel on Windows

The CMake script can be configured to build Python bindings using the BUILD_PYTHON_BINDINGS option (be aware that some problems have been reported in the Github issue).

Make sure you have Python installed. In case you want to compile for debugging, make sure to include the debug symbols when installing Python, for example by running the following install command (see docs.python.org):

python-3.13.3-amd64.exe /quiet Include_debug=1 \
                               Include_dev=1 \
                               Include_lib=1 \
                               Include_pip=1 \
                               PrependPath=1 \
                               CompileAll=1 \
                               InstallAllUsers=0

Building the Python bindings requires numpy. Install the latest version with pip install numpy.

To install the other dependencies use the build-dependencies-msvc.bat batch script. Open a terminal in the Essentia root folder and run

.\packaging\build-dependencies-msvc.bat --static --build-type Release

The --static flag will build static libraries and the --build-type Release option will use the release configuration (default is Debug). Now you should be ready to configure with CMake and build:

cmake -B build -DUSE_TENSORFLOW=ON \
               -DBUILD_PYTHON_BINDINGS=ON \
               -DENABLE_STATIC_DEPENDENCIES=ON \
               -DCMAKE_PREFIX_PATH=%CD%\packaging\msvc

cmake --build build --config Release --parallel

The ENABLE_STATIC_DEPENDENCIES option will set some MSVC specific compiler options to ensure static dependencies are used (be aware that TensorFlow is available as a shared library only, see remarks below). The final wheel should then be available in the build\wheel subfolder.

You can test the wheel in a virtual environment:

python -m venv essentia-test
cd essentia-test
Scripts\activate.bat
pip install C:/path/to/essentia/build/wheel/essentia-2.1b6.dev0-cp313-cp313-win_amd64.whl

A simple Essentia test could look something like

import essentia
import essentia.standard as es

# Loading audio file
audio = es.MonoLoader(filename='C:/path/to/some/audio.mp3')()

# Compute beat positions and BPM
rhythm_extractor = es.RhythmExtractor2013(method="multifeature")
bpm, beats, beats_confidence, _, intervals = rhythm_extractor(audio)

print("BPM:", bpm)
print("Beat positions (sec.):", beats)

TensorFlow

When trying to run the above Python test, you will most likely get an error like ImportError: DLL load failed while importing _essentia. This is because Python cannot load the TensorFlow DLL. There are a couple of ways to fix this:

  • In case you won’t be using TensorFlow models, compile Essentia without setting USE_TENSORFLOW=ON.
  • Tell Python where to look for the TensorFlow DLL using os.add_dll_directory.
  • Copy the TensorFlow DLL to the Essentia wheel installation directory (alongside the _essentia.cp313-win_amd64.pyd file).

Building Essentia on Linux

In this section you can find concise instructions on how to build Essentia using CMake on Linux. In case you want to use SVM machine learning models, you will have to build and install Gaia locally. For TensorFlow models, follow the instructions on tensorflow.org.

Debian

Make sure basic build tools are installed:

sudo apt install build-essential

Next, install CMake and dependencies:

sudo apt install cmake \
  libeigen3-dev \
  libyaml-dev \
  libfftw3-dev \
  libavcodec-dev \
  libavformat-dev \
  libavutil-dev \
  libswresample-dev \
  libsamplerate0-dev \
  libtag1-dev \
  libchromaprint-dev

Add python3-dev and python3-numpy to build Python bindings, vamp-plugin-sdk for the VAMP plugin. Then follow the CMake build instructions above.

Fedora

Make sure basic build tools are installed:

sudo dnf groupinstall "C Development Tools and Libraries" "Development Tools"

Next, install CMake and dependencies:

sudo dnf install cmake \
  eigen3-devel \
  libyaml-devel \
  libavcodec-free-devel \
  libavformat-free-devel \
  libavutil-free-devel \
  libswresample-free-devel \
  fftw-devel \
  taglib-devel \
  libsamplerate-devel \
  libchromaprint-devel

Add python3-devel and python3-numpy to build Python bindings (you might also need patchelf), vamp-plugin-sdk-devel for the VAMP plugin. Then follow the CMake build instructions above.

Arch Linux

Make sure basic build tools are installed:

sudo pacman -S base-devel --needed

Next, install CMake and dependencies:

sudo pacman -S cmake eigen libyaml ffmpeg fftw taglib libsamplerate chromaprint

Add python-numpy to build Python bindings, vamp-plugin-sdk for the VAMP plugin. Then follow the CMake build instructions above.

Building with MSYS2

For mingw64 the package names are

mingw-w64-x86_64-eigen3
mingw-w64-x86_64-ffmpeg
mingw-w64-x86_64-fftw
mingw-w64-x86_64-taglib
mingw-w64-x86_64-libsamplerate
mingw-w64-x86_64-libyaml
mingw-w64-x86_64-chromaprint
mingw-w64-x86_64-vamp-plugin-sdk

For ucrt64, add -ucrt after mingw-w64, for example mingw-w64-ucrt-x86_64-eigen3.

Please use the contact form or Github for comments.
